FS1425500UB
| Art nr | 106912 |
| Gross weight (kg)? | 500 |
| Load (kg)? | 325 |
| Int dimensions (cm)? | 250x138x26 |
| Brakes | No |
| Tip | Yes |
Trailers with low centre of gravity for easy loading
Serie FS
- Smooth release with a tip
- Foldable front and back strap
Only available in Sweden and Norway. The FS series offers robust and reliable recreational trailers in both braked and unbraked versions. With a tipping function and folding front and rear flaps, it is easy to handle everything from garden waste to building materials. A stable V-drawbar and protected electrical system increase safety, and the trailers are equipped with welded corner posts and durable birch floors for long durability. The FS series has made everyday life easier for tens of thousands of Swedish homeowners, and thanks to a wide range of accessories, you can tailor the trailer to your needs. The trailer in the picture may have additional equipment.
FS1425650UB
Art nr 106913 Gross weight (kg)? 650 Load (kg)? 475 Int dimensions (cm)? 250x138x26 Brakes No Tip Yes
FS1425750UB
Art nr 106915 Gross weight (kg)? 750 Load (kg)? 575 Int dimensions (cm)? 250x138x26 Brakes No Tip Yes
FS1425750B
Art nr 106914 Gross weight (kg)? 750 Load (kg)? 535 Int dimensions (cm)? 250x138x26 Brakes Yes Tip Yes
Appendice
- Steel platform
- Possibility of combining it with a 600 kg "B" type trolley
- Opening front and rear side panels
Only available in Italy. Trailers ideal for transporting luggage, small tools or similar. The galvanized steel platform and small size make this series versatile and guarantee maximum driving stability in every situation. The LARGE model is equipped with four opening sides that make it unique in its kind and an absolute novelty in the Italian panorama. The dimensions and characteristics of this series allow the trailer to be combined with the car as a type B “appendix”, or to be registered as a trailer.
Serie 1000
- Vertical storage possible
- Easy securing of your load
- Some models have tilt as standard
Small versatile trailers suitable for do it yourself purposes: from camping and leisure to moving garden waste ang goods. All trailers comes with a V-shaped drawbar that helps you in driving safely to you destination. The trailer can be easily stored in a vertical position in order to save space. Huge accessory program available. Images are for illustrative purposes only and may show optional equipment.
1150SUB500
Art nr 313140 Gross weight (kg)? 500 Load (kg)? 400 Int dimensions (cm)? 144x94x35 Brakes No Tip Yes 1150SUB500
Art nr 313142 Gross weight (kg)? 500 Load (kg)? 400 Int dimensions (cm)? 144x94x35 Brakes No Tip Yes
1150SUB602
Art nr 313141 Gross weight (kg)? 600 Load (kg)? 500 Int dimensions (cm)? 144x94x35 Brakes No Tip Yes
1150SUB500
Art nr 313144 Gross weight (kg)? 600 Load (kg)? 400 Int dimensions (cm)? 144x94x35 Brakes No Tip Yes
1205SUB500
Art nr 310969 Gross weight (kg)? 500 Load (kg)? 370 Int dimensions (cm)? 204x116x35 Brakes No Tip Yes
1203SUB500
Art nr 313942 Gross weight (kg)? 500 Load (kg)? 375 Int dimensions (cm)? 204x116x35 Brakes No Tip No 1203SUB750
Art nr 313943 Gross weight (kg)? 750 Load (kg)? 625 Int dimensions (cm)? 204x116x35 Brakes No Tip No
1205SUB500
Art nr 311083 Gross weight (kg)? 500 Load (kg)? 375 Int dimensions (cm)? 204x116x35 Brakes No Tip No 1205SUB600
Art nr 311107 Gross weight (kg)? 600 Load (kg)? 470 Int dimensions (cm)? 204x116x35 Brakes No Tip Yes 1205SUB750
Art nr 311106 Gross weight (kg)? 750 Load (kg)? 620 Int dimensions (cm)? 204x116x35 Brakes No Tip Yes 1205SUB750
Art nr 311108 Gross weight (kg)? 750 Load (kg)? 620 Int dimensions (cm)? 204x116x35 Brakes No Tip Yes
1205SUB750
Art nr 311323 Gross weight (kg)? 750 Load (kg)? 605 Int dimensions (cm)? 204x116x35 Brakes No Tip Yes
1205SUB500
Art nr 311326 Gross weight (kg)? 750 Load (kg)? 370 Int dimensions (cm)? 204x116x35 Brakes No Tip No 1205SUB750
Art nr 313944 Gross weight (kg)? 750 Load (kg)? 625 Int dimensions (cm)? 204x116x35 Brakes No Tip No
1205SB750
Art nr 307137 Gross weight (kg)? 750 Load (kg)? 590 Int dimensions (cm)? 204x116x35 Brakes Yes Tip No
1205SB750
Art nr 311327 Gross weight (kg)? 750 Load (kg)? 590 Int dimensions (cm)? 204x116x35 Brakes Yes Tip No
1205SXLUB750
Art nr 311017 Gross weight (kg)? 750 Load (kg)? 605 Int dimensions (cm)? 204x116x55 Brakes No Tip Yes 1205SXLUB750
Art nr 311114 Gross weight (kg)? 750 Load (kg)? 605 Int dimensions (cm)? 204x116x55 Brakes No Tip Yes
1205SXLUB750
Art nr 311325 Gross weight (kg)? 750 Load (kg)? 605 Int dimensions (cm)? 204x116x55 Brakes No Tip Yes
1205SUBXL750
Art nr 311390 Gross weight (kg)? 750 Load (kg)? 605 Int dimensions (cm)? 116x204x55 Brakes No Tip Yes 1205SXLUB500
Art nr 316979 Gross weight (kg)? 500 Load (kg)? 355 Int dimensions (cm)? 204x116x55 Brakes No Tip Yes
1203SUB750
Art nr 317586 Gross weight (kg)? 750 Load (kg)? 625 Int dimensions (cm)? 204x116x35 Brakes No Tip No
Serie 2000
- 40 cm reinforced side panels
- Low load height
- Internal lashing eyes as standard
The 2000 series are a durable flatbed trailers that has a low load height and high reinforced side panels as standard. An easy to load trailer, they come in a range of sizes with single or twin axle and braked versions. There are also tilt versions with back panel ramps available. All versions are fitted with with internal lashing eyes for secure loading of goods. As always Brenderup offers a wide accessory program for our trailers. Images are for illustrative purposes only and may show optional equipment.
2205SUB500
Art nr 311764 Gross weight (kg)? 500 Load (kg)? 325 Int dimensions (cm)? 204x128x40 Brakes No Tip No 2205SUB750
Art nr 311763 Gross weight (kg)? 750 Load (kg)? 575 Int dimensions (cm)? 204x128x40 Brakes No Tip No
2205SUB750
Art nr 311825 Gross weight (kg)? 750 Load (kg)? 575 Int dimensions (cm)? 204x128x40 Brakes No Tip No 2205SUB750
Art nr 311826 Gross weight (kg)? 750 Load (kg)? 575 Int dimensions (cm)? 204x128x40 Brakes No Tip No
2205SB750
Art nr 316917 Gross weight (kg)? 750 Load (kg)? 530 Int dimensions (cm)? 204x128x40 Brakes Yes Tip 2205SB1000
Art nr 311766 Gross weight (kg)? 1000 Load (kg)? 780 Int dimensions (cm)? 204x128x40 Brakes Yes Tip No
2205SB750
Art nr 316904 Gross weight (kg)? 750 Load (kg)? 530 Int dimensions (cm)? 204x128x40 Brakes Yes Tip No 2205SB1000
Art nr 311789 Gross weight (kg)? 900 Load (kg)? 780 Int dimensions (cm)? 204x128x40 Brakes Yes Tip No 2205SB1000
Art nr 311788 Gross weight (kg)? 1000 Load (kg)? 780 Int dimensions (cm)? 204x128x40 Brakes Yes Tip No
2205AUB750
Art nr 311765 Gross weight (kg)? 750 Load (kg)? 575 Int dimensions (cm)? 204x128x40 Brakes No Tip No
2205AB1000
Art nr 311767 Gross weight (kg)? 1000 Load (kg)? 780 Int dimensions (cm)? 204x128x40 Brakes Yes Tip No
2260SUB500
Art nr 311792 Gross weight (kg)? 500 Load (kg)? 285 Int dimensions (cm)? 258x128x40 Brakes No Tip No
2260STUB500
Art nr 311815 Gross weight (kg)? 500 Load (kg)? 252 Int dimensions (cm)? 259x128x40 Brakes No Tip No
2260SUB750
Art nr 311791 Gross weight (kg)? 750 Load (kg)? 545 Int dimensions (cm)? 258x128x40 Brakes No Tip No
2260SUB750
Art nr 311794 Gross weight (kg)? 750 Load (kg)? 545 Int dimensions (cm)? 258x128x40 Brakes No Tip No 2260SUB750
Art nr 311795 Gross weight (kg)? 750 Load (kg)? 545 Int dimensions (cm)? 258x128x40 Brakes No Tip No 2260STUB750
Art nr 311814 Gross weight (kg)? 750 Load (kg)? 502 Int dimensions (cm)? 259x128x40 Brakes No Tip No
2260SB1300
Art nr 311796 Gross weight (kg)? 1300 Load (kg)? 1020 Int dimensions (cm)? 258x128x40 Brakes Yes Tip No 2260SB1300
Art nr 311799 Gross weight (kg)? 1300 Load (kg)? 1020 Int dimensions (cm)? 258x128x40 Brakes Yes Tip No
2260AUB750
Art nr 311793 Gross weight (kg)? 750 Load (kg)? 545 Int dimensions (cm)? 258x128x40 Brakes No Tip No
2260AB1300
Art nr 311798 Gross weight (kg)? 1300 Load (kg)? 1020 Int dimensions (cm)? 258x128x40 Brakes Yes Tip No
2260WSUB750
Art nr 311800 Gross weight (kg)? 750 Load (kg)? 490 Int dimensions (cm)? 258x153x40 Brakes No Tip Yes
2260WSUB750
Art nr 311851 Gross weight (kg)? 750 Load (kg)? 490 Int dimensions (cm)? 258x153x26 Brakes No Tip Yes
2260WSUB750
Art nr 311853 Gross weight (kg)? 750 Load (kg)? 490 Int dimensions (cm)? 258x153x26 Brakes No Tip Yes 2260WSB750 TILT
Art nr 316905 Gross weight (kg)? 750 Load (kg)? 495 Int dimensions (cm)? 258x153x26 Brakes Yes Tip Yes
2260WSB750 TILT
Art nr 316918 Gross weight (kg)? 750 Load (kg)? 495 Int dimensions (cm)? 258x153x26 Brakes Yes Tip Yes
2260WSB1000
Art nr 311811 Gross weight (kg)? 1000 Load (kg)? 680 Int dimensions (cm)? 258x153x26 Brakes Yes Tip Yes 2260WSB1000
Art nr 311854 Gross weight (kg)? 1000 Load (kg)? 680 Int dimensions (cm)? 258x153x26 Brakes Yes Tip Yes 2260WSB1000
Art nr 311855 Gross weight (kg)? 1000 Load (kg)? 680 Int dimensions (cm)? 258x153x26 Brakes Yes Tip Yes
2260WSB1300
Art nr 311803 Gross weight (kg)? 1300 Load (kg)? 980 Int dimensions (cm)? 258x153x40 Brakes Yes Tip Yes 2260WSB1300
Art nr 311804 Gross weight (kg)? 1300 Load (kg)? 980 Int dimensions (cm)? 258x153x40 Brakes Yes Tip Yes
2270SUB750
Art nr 311770 Gross weight (kg)? 750 Load (kg)? 540 Int dimensions (cm)? 270x129x26 Brakes No Tip No
2270SUB750
Art nr 311774 Gross weight (kg)? 750 Load (kg)? 540 Int dimensions (cm)? 270x129x26 Brakes No Tip No
2300STUB750
Art nr 311779 Gross weight (kg)? 750 Load (kg)? 445 Int dimensions (cm)? 300x153x40 Brakes No Tip No
2300SB1300
Art nr 311775 Gross weight (kg)? 1300 Load (kg)? 985 Int dimensions (cm)? 302x153x40 Brakes Yes Tip No
2300SB1300
Art nr 311776 Gross weight (kg)? 1300 Load (kg)? 985 Int dimensions (cm)? 302x153x40 Brakes Yes Tip No
2300SB1300
Art nr 311777 Gross weight (kg)? 1300 Load (kg)? 960 Int dimensions (cm)? 302x153x40 Brakes Yes Tip Yes
2300SB1300
Art nr 311778 Gross weight (kg)? 1300 Load (kg)? 960 Int dimensions (cm)? 302x153x40 Brakes Yes Tip Yes
2300STB2000
Art nr 311780 Gross weight (kg)? 2000 Load (kg)? 1620 Int dimensions (cm)? 302x153x40 Brakes Yes Tip No
2300STB2000
Art nr 311781 Gross weight (kg)? 2000 Load (kg)? 1620 Int dimensions (cm)? 302x153x40 Brakes Yes Tip No 2300STB2500
Art nr 311783 Gross weight (kg)? 2500 Load (kg)? 2080 Int dimensions (cm)? 302x153x40 Brakes Yes Tip No
2300ATB2000
Art nr 311782 Gross weight (kg)? 2000 Load (kg)? 1620 Int dimensions (cm)? 302x153x40 Brakes Yes Tip No
2300SUB750
Art nr 317020 Gross weight (kg)? 750 Load (kg)? 410 Int dimensions (cm)? 300x153x40 Brakes No Tip Yes
2270SXLUB750
Art nr 317024 Gross weight (kg)? 750 Load (kg)? 535 Int dimensions (cm)? 270x129x40 Brakes No Tip No
Serie D
Only available in Sweden. Professional trailer for construction or building work with a low center of gravity for increased safety and stable driving characteristics. The D-series is a reliable choice for transporting small machinery and is easy to load and unload. The trailer in the picture may have additional equipment.
D0650U
Art nr 106844 Gross weight (kg)? 650 Load (kg)? 380 Int dimensions (cm)? 325x152x26 Brakes No Tip Yes D0750U
Art nr 106847 Gross weight (kg)? 750 Load (kg)? 480 Int dimensions (cm)? 325x152x26 Brakes No Tip Yes
D0750B
Art nr 106845 Gross weight (kg)? 750 Load (kg)? 440 Int dimensions (cm)? 325x152x26 Brakes Yes Tip Yes D1000B
Art nr 106855 Gross weight (kg)? 1000 Load (kg)? 680 Int dimensions (cm)? 325x152x26 Brakes Yes Tip Yes D1250B
Art nr 106862 Gross weight (kg)? 1250 Load (kg)? 940 Int dimensions (cm)? 325x152x26 Brakes Yes Tip Yes
D1500B
Art nr 106872 Gross weight (kg)? 1500 Load (kg)? 1160 Int dimensions (cm)? 325x152x26 Brakes Yes Tip No
D1500TB
Art nr 106870 Gross weight (kg)? 1500 Load (kg)? 1085 Int dimensions (cm)? 325x152x26 Brakes Yes Tip No D2000TB
Art nr 106874 Gross weight (kg)? 1990 Load (kg)? 1565 Int dimensions (cm)? 325x152x26 Brakes Yes Tip No
Serie L
Only available in Sweden. Stable all-round trailer for professionals, with excellent load capacity and good driving characteristics. The platform is adapted to building board dimensions and the sides are foldable both front and rear. The areas of use become extra wide if you look at our accessory range. The trailer in the picture may be equipped with extras.
L650U
Art nr 301328 Gross weight (kg)? 650 Load (kg)? 460 Int dimensions (cm)? 258x128x26 Brakes No Tip No L750U
Art nr 300935 Gross weight (kg)? 750 Load (kg)? 560 Int dimensions (cm)? 258x128x26 Brakes No Tip No
L0750
Art nr 106956 Gross weight (kg)? 750 Load (kg)? 530 Int dimensions (cm)? 258x128x26 Brakes Yes Tip No
L0751
Art nr 106957 Gross weight (kg)? 750 Load (kg)? 510 Int dimensions (cm)? 258x128x26 Brakes Yes Tip No L1000
Art nr 106969 Gross weight (kg)? 1000 Load (kg)? 760 Int dimensions (cm)? 258x128x26 Brakes Yes Tip No L1001
Art nr 106971 Gross weight (kg)? 1000 Load (kg)? 760 Int dimensions (cm)? 258x128x26 Brakes Yes Tip No L1250
Art nr 106977 Gross weight (kg)? 1250 Load (kg)? 990 Int dimensions (cm)? 258x128x26 Brakes Yes Tip No L1251
Art nr 106979 Gross weight (kg)? 1250 Load (kg)? 990 Int dimensions (cm)? 258x128x26 Brakes Yes Tip No
Serie LM/LMT
Robust and flexible trailers for building materials and gardening. Compared to the L-series, the flatbed area and capacity are larger. The flatbed area is adapted to a building board size. Several options for the height of the side flaps. Folding front and rear flaps. Also available in an unbraked version. The LMT has extra high side panels. The trailer in the picture may have additional equipment.
LM650U
Art nr 106980 Gross weight (kg)? 650 Load (kg)? 440 Int dimensions (cm)? 270x138x26 Brakes No Tip Yes LM750U
Art nr 106982 Gross weight (kg)? 750 Load (kg)? 540 Int dimensions (cm)? 270x138x26 Brakes No Tip Yes
LM750
Art nr 106981 Gross weight (kg)? 750 Load (kg)? 510 Int dimensions (cm)? 270x138x26 Brakes Yes Tip Yes LM751
Art nr 106983 Gross weight (kg)? 750 Load (kg)? 490 Int dimensions (cm)? 270x138x26 Brakes Yes Tip Yes LM1000
Art nr 106985 Gross weight (kg)? 1000 Load (kg)? 740 Int dimensions (cm)? 270x138x26 Brakes Yes Tip Yes LM1200
Art nr 106986 Gross weight (kg)? 1250 Load (kg)? 980 Int dimensions (cm)? 270x138x26 Brakes Yes Tip Yes
LMT650U
Art nr 106987 Gross weight (kg)? 650 Load (kg)? 430 Int dimensions (cm)? 270x138x38 Brakes No Tip Yes
LMT750U
Art nr 106989 Gross weight (kg)? 750 Load (kg)? 530 Int dimensions (cm)? 270x138x38 Brakes No Tip Yes
LMT750
Art nr 106988 Gross weight (kg)? 750 Load (kg)? 500 Int dimensions (cm)? 270x138x38 Brakes Yes Tip Yes
LMT751
Art nr 106990 Gross weight (kg)? 750 Load (kg)? 480 Int dimensions (cm)? 270x138x38 Brakes Yes Tip Yes
LMT1000
Art nr 106991 Gross weight (kg)? 1000 Load (kg)? 730 Int dimensions (cm)? 270x138x38 Brakes Yes Tip Yes
LMT1250
Art nr 106992 Gross weight (kg)? 1250 Load (kg)? 970 Int dimensions (cm)? 270x138x38 Brakes Yes Tip Yes
RT-series
Only available in Sweden. Extra robust trailers with a wide flatbed for heavier, volume-intensive transport. Perfect for small machinery and construction work. Easy handling when loading and unloading. Low centre of gravity for better driving characteristics. The trailer in the picture may have additional equipment.
RT0750B
Art nr 107025 Gross weight (kg)? 750 Load (kg)? 430 Int dimensions (cm)? 258x152x38 Brakes Yes Tip Yes RT1000B
Art nr 107028 Gross weight (kg)? 1000 Load (kg)? 680 Int dimensions (cm)? 258x152x38 Brakes Yes Tip Yes RT1250B
Art nr 107040 Gross weight (kg)? 1250 Load (kg)? 930 Int dimensions (cm)? 258x152x38 Brakes Yes Tip Yes
RT1500TB
Art nr 107046 Gross weight (kg)? 1500 Load (kg)? 1085 Int dimensions (cm)? 258x152x38 Brakes Yes Tip No RT2000TB
Art nr 107047 Gross weight (kg)? 1990 Load (kg)? 1575 Int dimensions (cm)? 258x152x38 Brakes Yes Tip No
S-series
Only available in Sweden. Like our entire range of trailers, the S series is robust and easy to drive. The series offers a wide range of different platform sizes with both braked and unbraked trailers. Fully welded with hot-dip galvanized chassis, all to withstand tough use. The trailers are equipped with internal tie-down eyes and all trailers in the series can or have been equipped with a tipping function. The trailer in the picture may be equipped with extra equipment.
S1533UB650
Art nr 107054 Gross weight (kg)? 650 Load (kg)? 380 Int dimensions (cm)? 325x152x26 Brakes No Tip No S1533UB750
Art nr 107055 Gross weight (kg)? 750 Load (kg)? 480 Int dimensions (cm)? 325x152x26 Brakes No Tip Yes
S1537U0750
Art nr 311645 Gross weight (kg)? 750 Load (kg)? 460 Int dimensions (cm)? 365x152x26 Brakes No Tip Yes
S15371000
Art nr 107056 Gross weight (kg)? 1000 Load (kg)? 670 Int dimensions (cm)? 365x152x26 Brakes Yes Tip Yes S15371240
Art nr 107058 Gross weight (kg)? 1240 Load (kg)? 910 Int dimensions (cm)? 365x152x26 Brakes Yes Tip Yes
S1945B1000 i
Art nr 316774 Gross weight (kg)? 1000 Load (kg)? 610 Int dimensions (cm)? 450x188x26 Brakes Yes Tip Yes S1945B1000 o
Art nr 316780 Gross weight (kg)? 1000 Load (kg)? 575 Int dimensions (cm)? 450x188x26 Brakes Yes Tip Yes S1938B1000 o
Art nr 316792 Gross weight (kg)? 1000 Load (kg)? 620 Int dimensions (cm)? 380x188x26 Brakes Yes Tip Yes S1938B1000 i
Art nr 316793 Gross weight (kg)? 1000 Load (kg)? 610 Int dimensions (cm)? 380x188x26 Brakes Yes Tip Yes S1945B1240 i
Art nr 316769 Gross weight (kg)? 1240 Load (kg)? 810 Int dimensions (cm)? 450x188x26 Brakes Yes Tip Yes S1945B1240 o
Art nr 316781 Gross weight (kg)? 1240 Load (kg)? 815 Int dimensions (cm)? 450x188x26 Brakes Yes Tip Yes S1938B1240 i
Art nr 316790 Gross weight (kg)? 1240 Load (kg)? 850 Int dimensions (cm)? 380x188x26 Brakes Yes Tip Yes S1938B1240 o
Art nr 316791 Gross weight (kg)? 1240 Load (kg)? 860 Int dimensions (cm)? 380x188x26 Brakes Yes Tip Yes
EXPLANATION OF SIGNS
S - Steel side panel
A - Aluminum side panel
T - Tandem (double shaft)
UB - Unbraked trailer
B - Braked trailer
D - Door (CE and 7000 series)
R - Ramp (CE and 7000 series)
W - Wide
HB - Highly built
H - High (CE)
L - Low (CE)
o - Outline (S-Series)
i - Inline (S-Series)
HOW TO INTERPRET THE MODEL NAMES
Example: 5420WATB3500
5420WATB3500 = Series 5000
5420WATB3500 = 420 cm long flat surface
5420WATB3500 = Wide model
5420WATB3500 = Aluminum side panel
5420WATB3500 = Tandem (dual shaft)
5420WATB3500 = Braked trailer
5420WATB3500 = Total weight
