S15371000
Features and benefits
External hooks
External hooks for securing your load
Internal lashing eyes
Internal lashing eyes which easily helps you to secure your load
Strong side locks
High quality side locks which firmly locks the panels
Reinforced side panel
For better stability and stronger trailer
Welded chassi
A welded chassis give a more robust and steady trailer
Foldable front panel
Foldable front panel to easier load the trailer and also enable you to transport longer goods.
Foldable back panel
Foldable back panel to easier load the trailer and also enable you to transport longer goods.
Aluminium hood
Screw tip
The trailer is equipped with screw tip
Cables protected
Closed V-shape drawbar for protection of cables
Specifications
| S15371000 | |
| Article number | 107056 |
| Gross weight (kg) ? | 1000 |
| Load (kg) ? | 670 |
| Unladen weight (kg) | 330 |
| Int dimensions (cm) ? | 365x152x26 |
| Inside measurements (cm) | 148 |
| Ext dimensions (cm) ? | 513x197x82 |
| Loading height (mm) | 550 |
| Type of sidepanel | Steel |
| Foldable back panel | Yes |
| Foldable front panel | Yes |
| Tip | Yes |
| Loading angle (°) | 12 |
| Type of tip | Screw |
| Tip-protection | No |
| Ramp | 1 x (1,52x0,26m) |
| Brakes | Yes |
| Number of axels | 1 |
| Tyre dimension | 155R13 |
| No of wheelbolts | 5 |
| Rim type | Steel |
| Mudguards | Non standable |
| Plug connection type ? | Spiral |
| Adaptercable | 13 |
| Jockey wheel | Yes |
| Internal lashing eyes | 8 |
| External hooks | 15 |
| Premounted cover buttons | No |
