2205SB750

Features and benefits

Foldable back panel

Foldable back panel to easier load the trailer and also enable you to transport longer goods.

Jockey wheel

Jockey wheel included as standard equipment for easy handling of trailer when not connected to the car

Internal lashing eyes

Internal lashing eyes which easily helps you to secure your load

Foldable front panel

Foldable front panel to easier load the trailer and also enable you to transport longer goods.

13-pol cable

The trailer is delivered with a modern 13-pol connector.

High sides 40 cm

40 cm high sides provides larger loading volume

Strong drawbar

Strong side locks

High quality side locks which firmly locks the panels

External hooks

External hooks for securing your load

Cover buttons

The trailer is prepared for flat and high covers, attachment for covers pre-assembled

Cover buttons

The trailer is prepared for flat and high covers, attachment for covers pre-assembled

Specifications Accessories Features and benefits

Specifications

2205SB750
Article number 316904
Gross weight (kg) ? 750
Load (kg) ? 530
Unladen weight (kg) 220
Int dimensions (cm) ? 204x128x40
Ext dimensions (cm) ? 350x178x95
Loading height (mm) 560
Type of sidepanel Steel
Foldable back panel Yes
Foldable front panel Yes
Foldable side panels No
Tip No
Prepared for tip No
Tip-protection No
Brakes Yes
Number of axels 1
Tyre dimension 155R13
No of wheelbolts 4
Rim type Steel
Plug connection type ? Straight
Adaptercable 13
Jockey wheel Yes
Coupling Steel sheet
Internal lashing eyes 4
External hooks 4
Premounted cover buttons Yes
EAN 5702623169045

Useful with

  • Flat cover

    1350x2100 dark gray to 2205
    Art nr308012

  • Front stand

    Ladder rack 1300mm widht
    Art nr112237

  • Accessory kit 2205

    Grey Flat cover & jockey wheel including clamp and bolts, for 2205. Max vertical load on JW 125 kg
    Art nr307999

  • Loading ramp

    Steel 1300x2050mm, with mounting kit. Max load 600kg for S-2000
    Art nr101639

  • Support bar alu

    Adjustable 1000-1450mm. Price per piece
    Art nr313032

  • Alu X8 155/80R13

    Wheel on 8 spoke black/silver aluminium rim, 4-hole, 155/80R13, 500kg
    Art nr316169

  • Alu X8 155/80R13 (mounted)

    Wheel on 8 spoke black/silver aluminium rim, 4-hole, 155/80R13, 500kg, mounted on trailer
    Art nr316169M

  • Railing kit

    1280x2030x400mm double alu extension, for 2205
    Art nr114933

  • Flat cover

    1350x2100 dark gray to 2205
    Art nr308012

  • Transparts trailer lock

    Trailer lock with long shank pad lock. Fits coupling in sheet metal and smaller cast, 1205, 2205, 2270, 4260, FS1425, LV, MC. For larger cast ball joints use 312519
    Art nr313945
