L1250

Features and benefits

Strong side locks

High quality side locks which firmly locks the panels

Foldable front panel

Foldable front panel to easier load the trailer and also enable you to transport longer goods.

Jockey wheel

Jockey wheel included as standard equipment for easy handling of trailer when not connected to the car

Welded chassi

A welded chassis give a more robust and steady trailer

13-pol cable

The trailer is delivered with a modern 13-pol connector.

External hooks

External hooks for securing your load

Foldable back panel

Foldable back panel to easier load the trailer and also enable you to transport longer goods.

Cables protected

Closed V-shape drawbar for protection of cables

Bedsize fits wood board

Bedsize fits construction size boards (120x260 cm)

Specifications Accessories Features and benefits

Specifications

L1250
Article number 106977
Gross weight (kg) ? 1250
Load (kg) ? 990
Unladen weight (kg) 260
Int dimensions (cm) ? 258x128x26
Ext dimensions (cm) ? 397x174x82
Loading height (mm) 550
Type of sidepanel Steel
Foldable back panel Yes
Foldable front panel Yes
Foldable side panels No
Tip No
Prepared for tip No
Tip-protection No
Brakes Yes
Number of axels 1
Tyre dimension 175R13C
No of wheelbolts 5
Rim type Steel
Mudguards Non standable
Plug connection type ? Straight
Adaptercable 13
Jockey wheel Yes
Coupling Casted
Internal lashing eyes 6
External hooks 15
Premounted cover buttons No
EAN 5702621069774

Useful with

  • Cover netframe 80 cm

    1280x2580x800mm gray, with 2 adjustable support bar, for L
    Art nr103844
  • Wheel

    165R13"C, 5 holes, unspiked
    Art nr305145
  • Alu X10 175R13C

    Wheel on 10 spoke black/silver aluminium rim, 5-hole, 175R13C, 730kg
    Art nr316173
  • Flat cover

    1280x2580mm black for 2260, L
    Art nr314513
  • Wheel

    165R13"C8, 5 holes, with spiked
    Art nr305147
  • Transparts trailer lock

    Trailer lock with long shank pad lock. Fits coupling in sheet metal and smaller cast, 1205, 2205, 2270, 4260, FS1425, LV, MC. For larger cast ball joints use 312519
    Art nr313945
  • Jockey wheel with mounting kit

    Jockey wheel 102200, clamp 101415, bracket 102814, screws and nuts. Max vertical load on JW 125kg
    Art nr110778
