180750B

Features and benefits

Cables protected

Closed V-shape drawbar for protection of cables

Keel roller cradle

Height adjustable in high quality

Quick-release light ramp

Easy removable light ramp with quick connect.

Waterproof wheel bearings

Allows you to drain the wheels of the boat and reducing the risk for corrosion on the brakes of the trailer.

Adjustable winch tower

Galvanized chassis

Extends the life time for your trailer.

Adjustable axles

By changing the wheelbase you can share the weight in an optimal way.

Specifications Accessories Features and benefits

Specifications

180750B
Article number 312123
Gross weight (kg) ? 750
Load (kg) ? 490
Unladen weight (kg) 260
Ext dimensions (cm) ? 585x191
Loading height (mm) 500
Tip-protection No
Brakes Yes
Number of axels 1
Adjustable Axle Yes
Tyre dimension 155R13
No of wheelbolts 4
Rim type Steel
Mudguards Non standable
Fully covered mudguards No
Adaptercable 13
Plug connection type ? Straight
Coupling Steel sheet
Max boat lenght (m) 5.4
Max boat lenght (ft) 18
Loading system Rollers
Keel rolls 4
Side rolls 6
Winch Manual
Lights included Yes
Light panel model Ramp
EAN 5702623121234

Useful with

  • Spare wheel holder

    Mount on trailer for easy access and transportation of sparewheel. For 16-30" boattrailer. Mounting kit for drawbar with U bolts.
    Art nr115419

  • Toolbox Boat/Universal Kit

    Black plastic toolbox, 52x22x28 cm. Use it to store tools, winch or lashing bands when not in use. The toolbox is equipped with a lock incl. two keys. The kit includes bracket and mounting kit. Fits for boat trailers and some other models.
    Art nr312741

  • Square tube clamp

    80x40mm, for bar 40x40mm. U-clamp for mounting side support rolls, boat support plates etc.
    Art nr103400

  • Brake wash kit

    Equipment to make it easier to rinse saltwater from the brake drum using a regular garden hose and fresh water. For brake drum 200x50.
    Art nr105181

  • Winch kit

    DL1402LBS / 37095301
    Art nr305450

  • Crossbar

    Bended with mounting kit for boat trailers 16/18/20"
    Art nr102410

  • Alu X8 155/80R13

    Wheel on 8 spoke black/silver aluminium rim, 4-hole, 155/80R13, 500kg
    Art nr316169

  • Alu X8 155/80R13 (mounted)

    Wheel on 8 spoke black/silver aluminium rim, 4-hole, 155/80R13, 500kg, mounted on trailer
    Art nr316169M

  • Crossbar

    Straight with mounting kit for boat trailers 16/18/20"
    Art nr102406

  • Winch DL1402 A

    With strap 7500mm, maximum tensile weight 635kg
    Art nr103564
