Support bar alu
Adjustable 1400-2200mm. Price per piece, only available in 12 packs
| Art nr | 313033 |
3251STB1000
Features and benefits
Foldable side panels
All sides foldable for easier loading and unloading of goods of the trailer
Jockey wheel
Jockey wheel included as standard equipment for easy handling of trailer when not connected to the car
Cover buttons
The trailer is prepared for flat and high covers, attachment for covers pre-assembled
Foldable back panel
Foldable back panel to easier load the trailer and also enable you to transport longer goods.
Strong side locks
High quality side locks which firmly locks the panels
13-pol cable
The trailer is delivered with a modern 13-pol connector.
Specifications
| 3251STB1000 | |
| Article number | 310998 |
| Gross weight (kg) ? | 1000 |
| Load (kg) ? | 750 |
| Unladen weight (kg) | 250 |
| Int dimensions (cm) ? | 250x142x35 |
| Ext dimensions (cm) ? | 409x150x99 |
| Loading height (mm) | 690 |
| Type of sidepanel | Steel |
| Foldable back panel | Yes |
| Foldable front panel | Yes |
| Foldable side panels | Yes |
| Tip | No |
| Brakes | Yes |
| Number of axels | 2 |
| Tyre dimension | 155R13 |
| No of wheelbolts | 4 |
| Rim type | Steel |
| Plug connection type ? | Straight |
| Adaptercable | 13 |
| Jockey wheel | Yes |
| Coupling | Steel sheet |
| Internal lashing eyes | 6 |
| Premounted cover buttons | Yes |
| EAN | 5702623109980 |
Useful with
Shock absorber kit
4 pieces. Up to 1500kg for single axle and 3000kg for boogi axles
Mesh side kit 50 cm
1420x2500x500mm. With loose legs, complete for 3250/3251S (2018-)
Cargo net
Black 1530x2600mm flexible net with elastic outer thread, for 3250SArt nr 115285
Accessory kit 3250/ES250
Grey Flat cover & jockey wheel including clamp and bolts, for ES250, 3250. Max vertical load on JW 125 kg
Bracket for jockey wheel
50x6x651 F320U, ES250
Jockey wheel
200x50mm, Ø48x420mm. Solid rubber with steel rimArt nr 116301
Lashing ring
25mmArt nr 101532
Transparts trailer lock
Trailer lock with disc pad lock for casted couplings. Fits all larger cast ball couplings (from 2000kg upwards). For ball coupling in sheet metal or smaller cast 313945.Art nr 312519
High side extension kit 35 cm
Steel, 1420x2500mm, for 3251
High cover with stand 83 cm
1500x2580x820mm gray, stand with square profiles, for 3250, 3251
Flat cover
1500x2580 gray to 3250/3251, ES250Art nr 302612
Meshside cover 50 cm
1500x2580x500mm dark gray, for 3251, ES250Art nr 302616
Transparts trailer lock
Trailer lock with long shank pad lock. Fits coupling in sheet metal and smaller cast, 1205, 2205, 2270, 4260, FS1425, LV, MC. For larger cast ball joints use 312519Art nr 313945
Jockey wheel
220x65mm Ø48mmx400mm, solid rubber with steel rim. Max vertical load 125kgArt nr 312229
Front stand
Ladder rack 1420mm, complete for S-3000
Spare wheel holder
For 4 holes 13" with bolt, kit and reinforcement plate for S-1000 (2015-)
