Stop wedge
Black plastic 800kg (max total weight 2500kg)
| Art nr | 306828 |
3205SUB750
Features and benefits
Cover buttons
The trailer is prepared for flat and high covers, attachment for covers pre-assembled
Foldable back panel
Foldable back panel to easier load the trailer and also enable you to transport longer goods.
13-pol cable
The trailer is delivered with a modern 13-pol connector.
Strong side locks
High quality side locks which firmly locks the panels
Internal lashing eyes
Internal lashing eyes which easily helps you to secure your load
Specifications
| 3205SUB750 | |
| Article number | 311297 |
| Gross weight (kg) ? | 750 |
| Load (kg) ? | 605 |
| Unladen weight (kg) | 145 |
| Int dimensions (cm) ? | 205x142x35 |
| Ext dimensions (cm) ? | 327x150x99 |
| Loading height (mm) | 690 |
| Type of sidepanel | Steel |
| Foldable back panel | Yes |
| Foldable front panel | Yes |
| Foldable side panels | No |
| Tip | No |
| Brakes | No |
| Number of axels | 1 |
| Tyre dimension | 145/80R13 |
| No of wheelbolts | 4 |
| Rim type | Steel |
| Plug connection type ? | Straight |
| Adaptercable | 13 |
| Jockey wheel | No |
| Coupling | Steel sheet |
| Internal lashing eyes | 4 |
| Premounted cover buttons | Yes |
| EAN | 5702623112973 |
