Cover stand 117 cm
1221x1500x1170mm (3150)
3150SUB750
Features and benefits
Strong side panel
Firm sidepanel which increases the stability of the trailer
Foldable front panel
Foldable front panel to easier load the trailer and also enable you to transport longer goods.
Cover buttons
The trailer is prepared for flat and high covers, attachment for covers pre-assembled
Foldable back panel
Foldable back panel to easier load the trailer and also enable you to transport longer goods.
Strong side locks
High quality side locks which firmly locks the panels
13-pol cable
The trailer is delivered with a modern 13-pol connector.
Internal lashing eyes
Internal lashing eyes which easily helps you to secure your load
Specifications
| 3150SUB750 | |
| Article number | 310981 |
| Gross weight (kg) ? | 750 |
| Load (kg) ? | 630 |
| Unladen weight (kg) | 120 |
| Int dimensions (cm) ? | 144x116x35 |
| Ext dimensions (cm) ? | 254x124x99 |
| Loading height (mm) | 655 |
| Type of sidepanel | Steel |
| Foldable back panel | Yes |
| Foldable front panel | No |
| Foldable side panels | No |
| Tip | No |
| Brakes | No |
| Number of axels | 1 |
| Tyre dimension | 145/80R13 |
| No of wheelbolts | 4 |
| Rim type | Steel |
| Plug connection type ? | Straight |
| Adaptercable | 13 |
| Jockey wheel | No |
| Coupling | Steel sheet |
| Internal lashing eyes | 4 |
| Premounted cover buttons | Yes |
| EAN | 5702623109812 |
Useful with
Bracket for jockey wheel
13,5 degrees
Stop wedge
Black plastic 800kg (max total weight 2500kg)Art nr 306828
Front stand
Ladder rack 1220mm widht, complete for S-1000, S-3000
Jockey wheel
200x50mm, Ø48x420mm. Solid rubber with steel rimArt nr 116301
Lashing ring
25mmArt nr 101532
Support bar alu
Adjustable 1000-1450mm. Price per pieceArt nr 313032
Flat cover
1236x1526x60mm gray, to 3150Art nr 302625
High cover with stand 117 cm
1160x1440x1170mm gray, stand with square profiles, to 3150
Transparts trailer lock
Trailer lock with disc pad lock for casted couplings. Fits all larger cast ball couplings (from 2000kg upwards). For ball coupling in sheet metal or smaller cast 313945.Art nr 312519
High side extension kit 35 cm
Steel, 1160x1440mm, for 3150
Mesh side kit 50 cm
1160x1440x500mm for 3150SMesh side kit 50 cm
1160x1440x500mm. With loose legs, complete for 3150S (2018-)
Holder for wheel chock
Black plastic, fits to 306828Art nr 306829
Meshside cover 50 cm
1230x1520x500mm gray, to 3150Art nr 302635
Mounting kit
For coverstand (2260)
Transparts trailer lock
Trailer lock with long shank pad lock. Fits coupling in sheet metal and smaller cast, 1205, 2205, 2270, 4260, FS1425, LV, MC. For larger cast ball joints use 312519Art nr 313945
Toolbox
300x1080mm, height 330mm. Complete, including srew kit for mounting on squareprofile drawbars, black plastic. For mounting on high drawbars add 4 U-bolts M12 74 / 135mm and 8 hex nuts M12High cover 117 cm
1220x1500x1170mm gray, for cover stand 3150Art nr 310465
