5420WATB3500

Features and benefits

Foldable side panels

All sides foldable for easier loading and unloading of goods of the trailer

External hooks

External hooks for securing your load

Steel profile protects the platform

Better protection when loading goods on the trailer

Jockey wheel

Jockey wheel included as standard equipment for easy handling of trailer when not connected to the car

Strong side panel

Firm sidepanel which increases the stability of the trailer

Internal lashing eyes

Internal lashing eyes which easily helps you to secure your load

Integrated side locks

Integrated side locks into the side panels

Foldable and removable side panels

All sides and corner posts are removable which makes it easier to load or onload goods from the trailer (driving without corner posts not allowed).

Foldable back panel

Foldable back panel to easier load the trailer and also enable you to transport longer goods.

13-pol coil cable

A spiral cable will always try to retract to their shortest length so it will end up suspended in mid air between the trailer and the ground, the design of the cord can have that extra flexibility without putting stress on the wire inside.

Foldable front panel

Foldable front panel to easier load the trailer and also enable you to transport longer goods.

Specifications Accessories Features and benefits

Specifications

5420WATB3500
Article number 308400
Gross weight (kg) ? 3500
Load (kg) ? 2830
Unladen weight (kg) 670
Int dimensions (cm) ? 417x203x34
Ext dimensions (cm) ? 543x210x109
Loading height (mm) 754
Type of sidepanel Aluminum
Foldable back panel Yes
Foldable front panel Yes
Foldable side panels Yes
Tip No
Brakes Yes
Number of axels 2
Tyre dimension 185R14C
No of wheelbolts 5
Rim type Steel
Plug connection type ? Spiral
Adaptercable 13
Jockey wheel Yes
Coupling Casted
Internal lashing eyes 8
External hooks 6
Premounted cover buttons No
EAN 5702623084003
