Lashing eye kit
Bended with nut, for S-5000
5420WATB3500
Features and benefits
Foldable side panels
All sides foldable for easier loading and unloading of goods of the trailer
External hooks
External hooks for securing your load
Steel profile protects the platform
Better protection when loading goods on the trailer
Jockey wheel
Jockey wheel included as standard equipment for easy handling of trailer when not connected to the car
Strong side panel
Firm sidepanel which increases the stability of the trailer
Internal lashing eyes
Internal lashing eyes which easily helps you to secure your load
Integrated side locks
Integrated side locks into the side panels
Foldable back panel
Foldable back panel to easier load the trailer and also enable you to transport longer goods.
Foldable front panel
Foldable front panel to easier load the trailer and also enable you to transport longer goods.
Specifications
| 5420WATB3500 | |
| Article number | 308357 |
| Gross weight (kg) ? | 3500 |
| Load (kg) ? | 2830 |
| Unladen weight (kg) | 670 |
| Int dimensions (cm) ? | 417x204x34 |
| Ext dimensions (cm) ? | 543x210x90 |
| Loading height (mm) | 754 |
| Type of sidepanel | Aluminum |
| Foldable back panel | Yes |
| Foldable front panel | Yes |
| Foldable side panels | Yes |
| Tip | No |
| Brakes | Yes |
| Number of axels | 2 |
| Tyre dimension | 185R14C |
| No of wheelbolts | 5 |
| Rim type | Steel |
| Plug connection type ? | Spiral |
| Adaptercable | 13 |
| Jockey wheel | Yes |
| Coupling | Casted |
| Internal lashing eyes | 8 |
| External hooks | 6 |
| Premounted cover buttons | No |
| EAN | 5702623083570 |
Useful with
Support bar alu
Adjustable 1400-2200mm. Price per piece, only available in 12 packsArt nr 313033
High cover 133 cm
2090x4220x1000mm gray for cover stand (5420W)Art nr 101307
Propstand kit (mount.)
Mounted on S5000 trailerArt nr 101941M
Verktygslåda
Frontmontering till serie 5000 komplett
Mounting kit
For coverstand (5000, 6000, RT)
Cover stand 150 cm
2040x4170x1500mm (5420W, 6420 with adapter)
Transparts trailer lock
Trailer lock with disc pad lock for casted couplings. Fits all larger cast ball couplings (from 2000kg upwards). For ball coupling in sheet metal or smaller cast 313945.Art nr 312519
Shock absorber kit
4 pieces. Up to 2000kg for single axle and 3500kg for boogi axles
High cover 150 cm
2040x4170x1500mm grey for cover stand (5420W, 6420)Art nr 101308
Loading ramp (mount.)
Steel, mounted on S-5000 trailer (2016-)
Holder for stop wedge
Steel, fits to 111563
Spare wheel holder
For 4 & 5 holesLoading ramp (mount.)
Steel, mounted on S-5000 trailerArt nr 309637M
Toolbox
Med plastlock. S5000 komplett
Jockey wheel
225X65mm Ø60mm, solid rubber with steel rim. Max vertical load 250kgArt nr 101432
Alu X10 185R14C (mounted)
Wheel on 10 spoke black/silver aluminium rim, 5-hole, 185R14C, 900kg, mounted on trailerArt nr 316171M
Propstand kit
Complete for S-5000
Stop wedge
Steel 1600kg, 150x320mm (max total weight 3500kg)
Flat cover
2040x4170 gray to 5420WArt nr 101884 Loading ramp
Steel ramps in pair, complete with ramp storage. Max load 1400kg / ramp for S-5000Alu X10 185R14C
Wheel on 10 spoke black/silver aluminium rim, 5-hole, 185R14C, 900kgArt nr 316171
Net frame kit 80 cm
2040x4200x800mm, for 5420W (2016-)Loading ramp
Aluminium, 2560mm for S-5000
High side extension kit 35 cm
Aluminium, 2040x4200x350mm , for 5420W (2016-)Cover stand 100 cm
2090x4220x1000mm (5420W)
