5420ATB2000
Features and benefits
Foldable side panels
All sides foldable for easier loading and unloading of goods of the trailer
External hooks
External hooks for securing your load
Steel profile protects the platform
Better protection when loading goods on the trailer
Jockey wheel
Jockey wheel included as standard equipment for easy handling of trailer when not connected to the car
Internal lashing eyes
Internal lashing eyes which easily helps you to secure your load
Integrated side locks
Integrated side locks into the side panels
13-pol coil cable
A spiral cable will always try to retract to their shortest length so it will end up suspended in mid air between the trailer and the ground, the design of the cord can have that extra flexibility without putting stress on the wire inside.
Specifications
| 5420ATB2000 | |
| Article number | 311316 |
| Gross weight (kg) ? | 2000 |
| Load (kg) ? | 1480 |
| Unladen weight (kg) | 520 |
| Int dimensions (cm) ? | 417x180x34 |
| Ext dimensions (cm) ? | 544x186x90 |
| Loading height (mm) | 714 |
| Type of sidepanel | Aluminum |
| Foldable back panel | Yes |
| Foldable front panel | Yes |
| Foldable side panels | Yes |
| Tip | No |
| Brakes | Yes |
| Number of axels | 2 |
| Tyre dimension | 155R13 |
| No of wheelbolts | 4 |
| Rim type | Steel |
| Plug connection type ? | Spiral |
| Adaptercable | 13 |
| Jockey wheel | Yes |
| Coupling | Steel sheet |
| Internal lashing eyes | 8 |
| External hooks | 6 |
| Premounted cover buttons | No |
| EAN | 5702623113161 |
