8815UBRA750

Features and benefits

Waterproof wheel bearings

Allows you to drain the wheels of the boat and reducing the risk for corrosion on the brakes of the trailer.

Keel roller

Adjustable height

Fully protected premium winch

Premium winch with cover to protect the belt from weather exposure and also reducing the risk of chrusching damages.

Galvanized chassis

Extends the life time for your trailer.

Adjustable axles

By changing the wheelbase you can share the weight in an optimal way.

Specifications Accessories Features and benefits

Specifications

8815UBRA750
Article number 317270
Gross weight (kg) ? 750
Load (kg) ? 630
Unladen weight (kg) 120
Ext dimensions (cm) ? 416x158
Max boat lenght (m) 3.8
Max boat lenght (ft) 13
Loading system Rails
Adjustable Axle Yes
Winch Manual
Light panel model Seperated LED
Brakes No
Number of axels 1
Tyre dimension 145/80R13
No of wheelbolts 4
Rim type Steel
Plug connection type ? Spiral
Adaptercable 13
External hooks 2
Fully covered mudguards No
Mudguards Non standable
Jockey wheel Yes

Useful with

  • Stop wedge

    Black plastic 800kg (max total weight 2500kg)
    Art nr306828

  • Lashing eye

    60x40mm for Jetski, with bolt & nut
    Art nr309681

  • Spare wheel holder

    Mount on trailer for easy access and transportation of sparewheel. For 16-30" boattrailer. Mounting kit for drawbar with U bolts.
    Art nr115419

  • Square tube clamp

    40x40mm, for bar 30x30mm. U-clamp for mounting side support rolls, boat support plates etc.
    Art nr100028

  • Alu X8 155/80R13

    Wheel on 8 spoke black/silver aluminium rim, 4-hole, 155/80R13, 500kg
    Art nr316169

  • Alu X8 155/80R13 (mounted)

    Wheel on 8 spoke black/silver aluminium rim, 4-hole, 155/80R13, 500kg, mounted on trailer
    Art nr316169M

  • Stand for boat

    Stand for easier access to the boat whilst it's on the trailer
    Art nr102382

  • Winch DL1402

    With black cover & strap 7500mm for maximum tensile weight 635kg
    Art nr306143

  • Tie down kit

    4 pieces with straps 2000mm & tightener. For fastening of the boat to the trailer, max. 2500kg
    Art nr106069
