New and 3 year warranty

16750UB X

  1. Easy-to-use Adjustable Telescoping Lights
  2. Fully waterproof LED lamps

Features and benefits

Telescopic lights

Telescopic extendable individual lights. Light units can be adjusted behind the trailer to increase your visibility on the road.

LED lamps

Enhanced visibility, durability, and safety with fully waterproof LED lamps, according to the IP69K standard and including lamp, connector, and cable.

Keel roller cradle

Height adjustable in high quality

Waterproof wheel bearings

Allows you to drain the wheels of the boat and reducing the risk for corrosion on the brakes of the trailer.

Multi-adjustable single front side rollers

Equipped with single side rollers in order to better protect your boat

Standable fully protected mudguards

Standable mudguards (90kg) and fully inside protected in order to protect the boat from gravel and spattering from the road.

Multi-adjustable double rear side rollers

Equipped with double side rollers in order to better protect your boat

Galvanized chassis

Extends the life time for your trailer.

Specifications Accessories Features and benefits

Specifications

16750UB X
Article number 317880
Gross weight (kg) ? 750
Load (kg) ? 540
Unladen weight (kg) 210
Ext dimensions (cm) ? 535x191
Brakes No
Number of axels 1
Adjustable Axle Yes
Tyre dimension 155R13
No of wheelbolts 4
Rim type Steel
Mudguards Standable
Fully covered mudguards Yes
Adaptercable 13
Plug connection type ? Spiral
Max boat lenght (m) 4.8
Max boat lenght (ft) 16
Loading system Rollers
Keel rolls 3
Side rolls 6
Winch Manual
Lights included Yes
Light panel model Telescopic_LED
EAN 5702623178801

Useful with

  • Supersoft step keel kit

    With 4 supersoft rollers Ø200x65 Hole 25mm, maximum keel height 80mm.
    Art nr101795

  • Rope hook

    Short model with bolts, 80x40mm for frame mounting, max load 400daN ( approx. 400kg)
    Art nr103418

  • Walking plank

    1615x200mm, Anti slip protected, complete with brackets for mounting.
    Art nr103410

  • Spare wheel holder

    Mount on trailer for easy access and transportation of sparewheel. For 16-30" boattrailer. Mounting kit for drawbar with U bolts.
    Art nr115419

  • Toolbox Boat/Universal Kit

    Black plastic toolbox, 52x22x28 cm. Use it to store tools, winch or lashing bands when not in use. The toolbox is equipped with a lock incl. two keys. The kit includes bracket and mounting kit. Fits for boat trailers and some other models.
    Art nr312741

  • Brake wash kit

    Equipment to make it easier to rinse saltwater from the brake drum using a regular garden hose and fresh water. For brake drum 200x50.
    Art nr105181

  • Walking plank

    3500x200mm, Anti slip protected, complete with brackets for mounting.
    Art nr103409

  • Alu X8 155/80R13

    Wheel on 8 spoke black/silver aluminium rim, 4-hole, 155/80R13, 500kg
    Art nr316169

  • Boat support

    1 piece complete including mounting kit. Boat support that's providing larger contact area to reduce impact on boat hull. Good for long transportation and/or when using trailer as permanent boat storage.
    Art nr102383

  • Stand for boat

    Stand for easier access to the boat whilst it's on the trailer
    Art nr102382

  • Brake wash kit (mount.)

    Equipment to make it easier to rinse saltwater from the brake drum using a regular garden hose and fresh water. For brake drum 200x50. Mounted on trailer
    Art nr105181M

  • Transparts trailer lock

    Trailer lock with long shank pad lock. Fits coupling in sheet metal and smaller cast, 1205, 2205, 2270, 4260, FS1425, LV, MC. For larger cast ball joints use 312519
    Art nr313945

  • Tie down kit

    4 pieces with straps 2000mm & tightener. For fastening of the boat to the trailer, max. 2500kg
    Art nr106069

  • Extension bracket

    Height increase bracket for keel roller, adjust height 60-80 mm, mounting kit 307558
    Art nr103022

  • Battery box

    Complete with console and mounting kit. For storage of cargo straps, battery, charger etc.
    Art nr304613
