Rope hook
Short model with bolts, 80x40mm for frame mounting, max load 400daN ( approx. 400kg)
263500TB ASR X
Features and benefits
Cables protected
Closed V-shape drawbar for protection of cables
Keel roller cradle
Height adjustable in high quality
Stainless steel brake wires
With a trailer with brakes, safety is higher and the braking distance is shorter.
Waterproof wheel bearings
Allows you to drain the wheels of the boat and reducing the risk for corrosion on the brakes of the trailer.
Standable fully protected mudguards
Standable mudguards (90kg) and fully inside protected in order to protect the boat from gravel and spattering from the road.
Reinforced keel roller
Reinforced keel roller with adjustable height
Safety wire on winch tower
Extra safety wire for securing the boat on the trailer, shall be used in combination with other strapping options.
Adjustable axles
By changing the wheelbase you can share the weight in an optimal way.
Specifications
| 263500TB ASR X | |
| Article number | 316108 |
| Gross weight (kg) ? | 3500 |
| Load (kg) ? | 2800 |
| Unladen weight (kg) | 700 |
| Ext dimensions (cm) ? | 803x221 |
| Loading height (mm) | 450 |
| Brakes | Yes |
| Number of axels | 2 |
| Adjustable Axle | Yes |
| Tyre dimension | 185R14C |
| No of wheelbolts | 5 |
| Rim type | Steel |
| Mudguards | Standable |
| Fully covered mudguards | Yes |
| Adaptercable | 13 |
| Plug connection type ? | Spiral |
| Coupling | Casted Iron |
| Max boat lenght (m) | 7.8 |
| Max boat lenght (ft) | 26 |
| Loading system | Adaptive Super Rollers |
| Keel rolls | 5 |
| Side rolls | 28 |
| Winch | Manual |
| Lights included | Yes |
| Light panel model | Seperated LED |
| EAN | 5702623161087 |
Useful with
Walking plank
1615x200mm, Anti slip protected, complete with brackets for mounting.
Spare wheel holder
Mount on trailer for easy access and transportation of sparewheel. For 16-30" boattrailer. Mounting kit for drawbar with U bolts.
Toolbox Boat/Universal Kit
Black plastic toolbox, 52x22x28 cm. Use it to store tools, winch or lashing bands when not in use. The toolbox is equipped with a lock incl. two keys. The kit includes bracket and mounting kit. Fits for boat trailers and some other models.
Keel boat equipment
Grey for boat 26"
Rope hook
Long model with bolts, 80x40mm for frame mounting
Brake wash kit
Equipment to make it easier to rinse saltwater from the brake drum using a regular garden hose and fresh water. For brake drum 200x50.
Winch
Winch d/l 2000B w/7,5m strapArt nr 304987
Boat guide kit
Boat center guide bars, Set of 2 pieces, for easier loading of your boat in current water or windy conditions, does not work with Self adusting cradle, super rollers or straight crossbar.Walking plank
3500x200mm, Anti slip protected, complete with brackets for mounting.
Shock absorber kit
2 pieces. Up to 2000kg for single axle and 3500kg for boogi axles
Boat support
1 piece complete including mounting kit. Boat support that's providing larger contact area to reduce impact on boat hull. Good for long transportation and/or when using trailer as permanent boat storage.
Stand for boat
Stand for easier access to the boat whilst it's on the trailer
Support kit
Hull support kit for transport stabilisation, 4 pieces with bracket
Vinch DL2500AB
Without cover, strap 10000mm, 1134kgArt nr 312913
Winch DL1402
With black cover & strap 7500mm for maximum tensile weight 635kg
Tie down kit
4 pieces with straps 2000mm & tightener. For fastening of the boat to the trailer, max. 2500kgArt nr 106069
Extension bracket
Height increase bracket for keel roller, adjust height 60-80 mm, mounting kit 307558Art nr 103022
Winch kit DL2500AB
Winch with 2 bow snubbers & black cover
Battery box
Complete with console and mounting kit. For storage of cargo straps, battery, charger etc.
