201500B ASR X

  1. Easy-to-use Adjustable Telescoping Lights
  2. Fully waterproof LED lamps

Features and benefits

Telescopic lights

Telescopic extendable individual lights. Light units can be adjusted behind the trailer to increase your visibility on the road.

LED lamps

Enhanced visibility, durability, and safety with fully waterproof LED lamps, according to the IP69K standard and including lamp, connector, and cable.

Multi-adjustable double front side rollers

Equipped with double side rollers in order to better protect your boat

Waterproof wheel bearings

Allows you to drain the wheels of the boat and reducing the risk for corrosion on the brakes of the trailer.

Standable fully protected mudguards

Standable mudguards (90kg) and fully inside protected in order to protect the boat from gravel and spattering from the road.

Reinforced keel roller

Reinforced keel roller with adjustable height

Specifications Accessories Features and benefits

Specifications

201500B ASR X
Article number 317796
Gross weight (kg) ? 1500
Load (kg) ? 1160
Unladen weight (kg) 340
Ext dimensions (cm) ? 611x191
Brakes Yes
Number of axels 1
Adjustable Axle Yes
Tyre dimension 185R14C
No of wheelbolts 5
Rim type Steel
Mudguards Standable
Fully covered mudguards Yes
Adaptercable 13
Plug connection type ? Spiral
Max boat lenght (m) 6
Max boat lenght (ft) 20
Loading system Adaptive Super Rollers
Keel rolls 4
Side rolls 12
Winch Manual
Lights included Yes
Light panel model Telescopic_LED
EAN 5702623177965

Useful with

  • Electric Winch Warn 3700DC

    With the capacity to move heavy loads quickly and easily. With incredible traction, the job becomes easier and more fun. Traction 1 864 kg, Remote control 3.7 m cable. Recommended cable 13 m.
    Art nr103568

  • Supersoft step keel kit

    With 4 supersoft rollers Ø200x65 Hole 25mm, maximum keel height 80mm.
    Art nr101795

  • Walking plank

    1615x200mm, Anti slip protected, complete with brackets for mounting.
    Art nr103410

  • Fjärrkontroll till elWinch

    Wireless, for Warn 3700-4700DC electric winch. Includes wireless transmitter, receiver, holder and mounting kit. Check the winch from up to 15m.
    Art nr106517

  • Spare wheel holder

    Mount on trailer for easy access and transportation of sparewheel. For 16-30" boattrailer. Mounting kit for drawbar with U bolts.
    Art nr115419

  • Toolbox Boat/Universal Kit

    Black plastic toolbox, 52x22x28 cm. Use it to store tools, winch or lashing bands when not in use. The toolbox is equipped with a lock incl. two keys. The kit includes bracket and mounting kit. Fits for boat trailers and some other models.
    Art nr312741

  • Battery

    Maxxima 50AH
    Art nr106583

  • Mounting kit battery winch

    For elevated winch tower, fits together with battery 106583 and battery box 304613
    Art nr102723

  • Winch bracket

    For electric winch Warn, with quick lock including mounting kit
    Art nr102726

  • Transparts trailer lock

    Trailer lock with disc pad lock for casted couplings. Fits all larger cast ball couplings (from 2000kg upwards). For ball coupling in sheet metal or smaller cast 313945.
    Art nr312519

  • Walking plank

    3500x200mm, Anti slip protected, complete with brackets for mounting.
    Art nr103409

  • Shock absorber kit

    2 pieces. Up to 2000kg for single axle and 3500kg for boogi axles
    Art nr113970

  • Boat support

    1 piece complete including mounting kit. Boat support that's providing larger contact area to reduce impact on boat hull. Good for long transportation and/or when using trailer as permanent boat storage.
    Art nr102383

  • Stand for boat

    Stand for easier access to the boat whilst it's on the trailer
    Art nr102382

  • Brake wash kit

    Equipment to make it easier to rinse saltwater from the brake drum using a regular garden hose and fresh water. For brake drum 250x40.
    Art nr314756

  • Alu X10 185R14C

    Wheel on 10 spoke black/silver aluminium rim, 5-hole, 185R14C, 900kg
    Art nr316171

  • ElWinch Warn 4000DC incl. mounting kit

    With the capacity to move heavy loads quickly and easily. With incredible traction, the job becomes easier and more fun. Traction 1 864 kg, Remote control 3.7 m cable. Recommended cable 13 m. Battery pack with drawers and bracket not included. Incl. mounting kit.
    Art nr103610

  • Brake wash kit (mount.)

    Equipment to make it easier to rinse saltwater from the brake drum using a regular garden hose and fresh water. For brake drum 250x40, mounted on trailer.
    Art nr314756M

  • Tie down kit

    4 pieces with straps 2000mm & tightener. For fastening of the boat to the trailer, max. 2500kg
    Art nr106069

  • Extension bracket

    Height increase bracket for keel roller, adjust height 60-80 mm, mounting kit 307558
    Art nr103022

  • Battery box

    Complete with console and mounting kit. For storage of cargo straps, battery, charger etc.
    Art nr304613
