AT2000

Features and benefits

Standable mudguards

Standable mudguards and extra steps for easier access to the machine loaded on the trailer

Anti slip ramps

Anti slip ramps for secure loading of your car

Hydraulic tip

Hydraulic tip as standard equipment

Low loading angle

A low loading angle makes it easier to load and unload cars

Back panel ramp

Welded and bolted chassi

A combination of welded parts with the benefits of the bolted parts for easy adjustments.

13-pol coil cable

A spiral cable will always try to retract to their shortest length so it will end up suspended in mid air between the trailer and the ground, the design of the cord can have that extra flexibility without putting stress on the wire inside.

Specifications Accessories Features and benefits

Specifications

AT2000
Article number 106741
Gross weight (kg) ? 1990
Load (kg) ? 1370
Unladen weight (kg) 620
Int dimensions (cm) ? 403x194x24
Ext dimensions (cm) ? 597x244x85
Loading height (mm) 470
Type of sidepanel Steel
Foldable back panel Yes
Foldable front panel No
Foldable side panels No
Tip Yes
Type of tip Hydraul-manual
Tip-protection No
Loading angle (°) 13
Ramp 1 x (2x0,2m)
Winch Manual
Brakes Yes
Number of axels 2
Tyre dimension 155R13
No of wheelbolts 5
Rim type Steel
Mudguards Standable
Coupling Casted
Plug connection type ? Removeable Spiral
Adaptercable 13
Jockey wheel Yes

Useful with

  • Transparts trailer lock

    Trailer lock with disc pad lock for casted couplings. Fits all larger cast ball couplings (from 2000kg upwards). For ball coupling in sheet metal or smaller cast 313945.
    Art nr312519
